ComfyNES Parametric Bench (Three-Profile)
A contoured slat bench with an added middle profile.
Instant download after checkout. All sales final. Digital products are non-refundable.
Version 1.0 · Prepared 2026-07
Screens
What it does
The two-profile bench covers a single smooth transition, but a bench that changes shape more deliberately along its length needs a third profile to control it. This Grasshopper definition (originally named ComfyNES 3S1R) lofts a contoured bench body from three section profiles along a single rail, then slices it into slats and threads steel rods through them, the same core mechanism as the Two-Profile version plus a middle profile for finer control. Slat count, slat thickness, rod radius, and colours are all inputs, with the same flip controls for curves and orientation plane. Swap in a middle profile and you shape the bench's silhouette along its length instead of settling for one smooth curve, all without remodeling from scratch.
What is included
- Rail plus three section profiles as inputs
- Number of slats and slat thickness controls
- Steel rod radius with rod and bench colours
- Flip controls for curves and orientation plane
- Example .3dm with the reference curves set up
- Uses eleFront (free) for organised baking
How it works
- 01
Open the .gh in Rhino 8 alongside your reference rail and three section curves.
- 02
Install eleFront (free, via the Rhino package manager) for organised baking.
- 03
Set slat count, slat thickness, and rod radius on the sliders.
- 04
Flip the curve or orientation-plane toggles if the geometry comes in backwards.
- 05
Bake the bench once the proportions read right.
Parameters
The sliders and inputs the tool exposes.
Questions about this product
Should I buy this or the Two-Profile version?
Pick Three-Profile when you want more control over how the bench changes shape along its length. Two-Profile is simpler and enough for a single smooth transition.
Do the two bench versions share inputs?
Yes. Both use a rail, section profiles, slat count, slat thickness, and rod radius, so moving between them is straightforward.
